PMC/P6P pallet

for air cargo

Introduction
The Aviation PMC Pallet is a standard air cargo pallet engineered to deliver outstanding strength, lightweight performance, and operational efficiency for airlines and cargo handling companies. Measuring 96 × 125 inches, it is designed to accommodate a wide range of cargo while maintaining compatibility with international aircraft cargo systems.
One of the pallet's key advantages is its light tare weight of only 97 kg, allowing operators to maximize payload capacity without compromising structural integrity. The PMC pallet supports a maximum gross weight of 6,804 kg, making it suitable for transporting heavy freight safely and efficiently.
Manufactured from high-quality aluminum alloys, the pallet frame is constructed with AL7003, the pallet sheet uses AL7021, and the corner connections are made from AL2A14. These premium materials provide excellent durability, corrosion resistance, and long-term reliability in demanding airport environments.
The Aviation PMC Pallet complies with internationally recognized standards, including CAAC CTSO-C90c, FAA TSO-C90c, and NAS3610-2M3P, ensuring safe and compliant operation across global air cargo networks.
Combining lightweight construction, high load capacity, and certified quality, the Aviation PMC Pallet is an ideal solution for airlines, freight forwarders, cargo terminals, and logistics providers seeking reliable and cost-effective unit load equipment for modern air cargo transportation.

Product Brief

• Material: Aluminium
• MOQ: 5 PCS
• Certification: CAAC / FAA

Product Description
Type: Aircraft pallet (PMC family)
IATA Code: PAG
ATA Code: P1
NAS Code: 2A4P
Loading capacity (typical): 6804 KG
Size (typical): 2235 mm (L) × 3175 mm (W)
Applicable aircraft: B747, B777, B747F, Airbus models and other compatible freighter/passenger aircraft

Size and Max capacity of popular models

• PAG / P1 / 2A4P — Model: XD21 — Dimension: 2235 mm × 3175 mm — Max capacity: 6804 KG
• PMC / P6 / 2M3P — Model: XD22 — Dimension: 2438 mm × 3175 mm — Max capacity: 6804 KG
• PLA / P9 / 2L3P — Model: XD23 — Dimension: 1534 mm × 3175 mm — Max capacity: 3175 KG
• PKC / - / 2K3P — Model: XD24 — Dimension: 1562 mm × 1534 mm — Max capacity: 1588 KG
• FQA — Model: XD25 — Dimension: 2438 mm × 1534 mm — Max capacity: 2450 KG

Detailed Images
Multiple high-detail images available showing top, underside and logo-marked PMC pallet variants for inspection of fittings, locking points and surface finish.

Technical specifications

• Model family: PMC
• Brand: CHEERSMETAL
• Code: PMC
• Material: Aluminium
• MOQ: 5 PCS
• IATA Code: PAG
• ATA Code: P1
• NAS Code: 2A4P
• Loading Capacity: 6804 KG
• Typical Size: 2235 mm (L) × 3175 mm (W)
• Certification: CAAC / FAA
• Applicable Aircraft: B747, B777, B747F, Airbus and other compatible models
