Ground support baggage cart BC-2515B

for airport terminalsfor passengersopen

Product overview
Designed for apron and airport baggage handling operations, the BC-2515B open maintenance trolley carries large volumes of passenger luggage and bulk cargo. Rated lifting capacity: 2000 kg. Features a wear-resistant, waterproof cargo deck and an integral storage location for the included protective waterproof cover. Operational temperature range: -40 to +40°C.

Key features

• Purpose-built for passenger luggage and bulk loads on the apron
• Mechanical parking brake with front-wheel locking (activated by the towing vehicle)
• Front swivel axle and solid array wheels for stable movement
• Foldable side walls with reinforced fixed front and rear walls
• Wear-resistant, waterproof floor and protected reflective elements at corners
• Storage provision and supplied protective waterproof cover
• Manual coupling device and at least two stop pads per trolley
• Maximum transport speed ≥25 km/h; customizable sizes and options on request

Technical specifications

• Model: BC-2515B
• Brand: CHEERSMETAL
• Lifting capacity: 2000 kg
• Height to cargo platform: up to 520 mm
• Platform length: 2500 mm
• Length with lowered tow bar: 3680 mm
• Overall width: 1500–1600 mm
• Wheel type: solid, array
• Front swivel axle; front and rear wheels same track
• Maximum transport speed: at least 25 km/h
• Weight: 500–600 kg
• Parking brake: mechanical with front-wheel lock (tractor-driven)
• Coupling device: manual
• Stop pads: minimum 2 per trolley
• Operating temperature range: -40 to +40°C
• Shipping quantity: 10 pcs/20'GP; 20 pcs/40'GP; 24 pcs/40'HQ

Recommended applications

• Apron baggage handling and transfer
• Loading, staging and warehouse operations at airports
• Handling oversized or bulk luggage and cargo

Packaging & shipping
Standard export packaging. Container quantities: 10 units per 20'GP; 20 units per 40'GP; 24 units per 40'HQ.

Manufacturer & services

• Manufacturer: CHEERSMETAL — OEM production with quality control processes
• Custom dimensions and configurations available on request
• Protective waterproof cover supplied with each trolley
• Export experience and after-sales support available
